STEEL PRODUCTS



Allsteel & Gypum Inc is a manufacturer and direct suppler of light gauge and structural steel framing.  We manufacture cut to length studs and joists, enabling the contractor to save on time, labor and unnecessary waste. We also stock a wide range of framing in different sizes and gauges. Allsteel & Gypsum is a member of the Steel Stud Manufactures Association (SSMA), which has recently launched a 3rd party inspection program in conjunction with the Architectural Testing company.

SSMA

At this time Allsteel & Gypsum is currently 3rd party approved and certified code compliant for Structural Stud and Track.

Allsteel is also a manufacturer of the Supreme Framing System (SSFSA). Supreme Framing is a newly designed wider flange drywall stud that utilizes superior yield strength steel to produce a premium product. The new wider flange offers significant savings over traditional studs.


The Supreme Benefits.

  • Engineered and Tested per 2006 IBC
  • Third Party Tested and Certified
  • Wider Flanges for Quick Clamping & Screw Placement
  • 57 KSI Steel - Reduces Screw Stripping
  • Multiple UL Approved Fire Rated Assemblies
  • Excellent Acoustical Performance
  • Easier Gypsum Installation = Lower Labor Costs
  • Fast Framing for Lower Costs
  • Easier to Tin Snip or Shear

*Supreme is currently the only proprietary non-structural Drywall Stud in the U.S Certified code compliant by Architectural Testing.

SSFSA



Steel Framing Components

  • Non-Load Bearing Steel Studs - 1 1/4" & 1 7/16”  Flange
    Widths- 1 5/8" - 2 1/2" - 3 5/8" - 4" & 6"
    Gauge – 25 (18mil)  - 20 (24mil Supreme) – 20(30mil)

  • Load Bearing Studs - 1 5/8” - 2” & 2 ½” Flange
    Widths- 2 1/2" - 3 5/8" - 4" - 6" - 8" – 10” – 12” & 14”
    Guage- 20(33mil) – 18(43mil) – 16(54mil) – 14(68mil) – 12(97mil)

  • Track
    Regular Leg (ST)
    Deep Leg (DT)
    Structural 1 ½” & 2” legs
    All Gauges available



Steel Framing Accessories

    * 3/4", 1 1/2" & 2" Channels x 16 GA.
    * 7/8 & 1 1/2 Furring Channel - 25 - 20 GA.
    * Custom Angles
    * Resilient Channel (RC-1)
    * Z - Furring (1/2" through 4")
    * Shaft Wall System
    * Slotted & Deflection Clips
    * Custom Clips
    * Sheet Metal (Cut to Size)
    * Hanger Wire & Tie Wire
    * Cats (16" & 24")



Technical Library

Logos



ALLSTEEL Submittal Builder



SSMA
SSMA Leeds



SSMA
SSMA Technical Library



Material safety data sheet (MSDS)



Material Certification



Product Identification



Note: For those sections where two different yield strengths (33 ksi and 50 ksi) are shown, the yield strength used in the design, if greater than 33 ksi, needs to be identified on the design and ordering of steel. (i.e., 600S162-54 (50 ksi))





Steel Diagram
